Gmon

A tool that allows you to monitor game servers inside a terminal. It provides real-time updates on server status, user list, and also monitors latency to the server which supports multiple types of query/packet types (e.g., server queries or ICMP). Will be supporting RCON commands in the future as well!

Supported Query Types

Type	Aliases	Games
a2s	source, valve, steam, goldsrc	Source/GoldSrc engine servers (CS2, TF2, Garry's Mod, Rust, ...)
quake3	q3, quake, cod, cod2, cod4, codmp, et	Quake 3 engine servers (Call of Duty 1/2/4, Quake 3, OpenArena, Wolfenstein: ET, ...)
minecraft	mc, minecraft-java, java, slp	Minecraft: Java Edition (Server List Ping)
bedrock	mcbe, mcpe, minecraft-bedrock, raknet	Minecraft: Bedrock Edition (RakNet unconnected ping)
gamespy1	gs1, gamespy	GameSpy v1 servers (Unreal Tournament, Battlefield 1942, ...)
gamespy3	gs3, minecraft-query, mcquery, bf2	GameSpy v3 servers (Battlefield 2, Minecraft's query listener)
fivem	cfx, gta5, redm, citizenfx	FiveM/RedM (CitizenFX) servers over HTTP

Run gmon --list-query-types to print this list from the program itself.

When --query isn't provided, the query type is guessed from the port (e.g., 27015-27030 -> A2S, 25565 -> Minecraft, 19132 -> Bedrock, 28960 -> Quake 3, 30120 -> FiveM).

# Monitor a Call of Duty 4 server.
gmon -d 192.168.1.10:28960 -q cod4

# Monitor a Minecraft server and remember it.
gmon -d play.example.net:25565 -q minecraft -S

# Print one line per query instead of starting the TUI.
gmon -b -I -d play.example.net:19132 -q bedrock

Adding Servers In The TUI

Servers no longer have to come from the command line. Start the program, then on the dashboard:

Key	Action
n	Opens the Add Server form
↑ ↓ / Tab	Moves between fields
← → (or Space)	Changes the query type, latency type and save toggle
Enter	Adds the server
Esc	Goes back

The form takes the address, port, query type (left on Auto it's guessed from the port), an optional query port, display name, query interval, timeout, latency type and whether to persist the server. The address is checked before the server is added, and adding it starts querying immediately — no restart needed. With Save on, the server is written to the store and comes back on the next launch.

Starting without any servers now drops you on an empty dashboard instead of exiting, so a fresh install can be set up entirely from the TUI.

Building & Installing

You will want to make sure you have Rust and Cargo installed. You can install them from here.

You can clone the project assuming you have git installed.

# Clone the repository
git clone https://github.com/gamemann/gmon.git

# Change directory to the project folder
cd gmon

By default, servers are stored using sqlite and you will need to have libsqlite3-dev installed on your system. You can install it using your package manager. For example, on Ubuntu/Debian you can use apt:

sudo apt install -y libsqlite3-dev

To install the project, you can use Cargo as well:

cargo install --path .

This should allow you to execute gmon from anywhere in your terminal (via the $PATH).

Usage

Servers can be added from the TUI (see Adding Servers In The TUI) or from the command line with the options below.

Command	Description	Default
-s --store	The storage type to use when persisting server settings. Currently, only sqlite is tested, but json will be supported in the future.	sqlite
--store-path	The path to the store file without the file extension since that's determined off of the storage type.	~/.config/gmon/store
-b --basic	Uses basic stdout messages instead of starting the TUI. Generally used for debugging or minimal output.	-
-v --version	Displays the current version of the program.	-
-h --help	Displays the help message.	-

General Settings

These are general settings that are stored in whatever store you specify. You can override these settings with command line arguments.

Logging

Command	Description	Default
l --log	The log levels to use. Separate multiple levels with a comma. Valid levels are fatal, error, warn, info, debug, and trace.	info,warn,error,fatal
-L --log-path	When specified, all log messages will be written to the specified file as well. Data formats are available! For example: ./logs/%Y-%m-%d.log	-
-B --log-buffer-size	The maximum number of log messages to keep in the log buffer before popping out the last one.	250

TUI

Command	Description	Default
-i --draw-interval	The interval in milliseconds to redraw the TUI.	500
-E --input-poll-interval	The interval in milliseconds to poll for user input.	500

Server Settings

Here are general server settings for adding, deleting, or overriding server configurations.

Command	Description
-d --dst	The destination IP address or hostname of the server you want to monitor or add/delete. You may also specify a port using the format IP:PORT.
-P -port	The port of the server you want to monitor or add/delete. This is optional if you specify the port in the --dst option.
-q --query	The query type to use when monitoring or adding the server (see Supported Query Types). If this option is not specified, the program will try to determine the query type based off of the port specified.
-Q --query-port	The port to use for the query. This is optional and will default to the port specified in --dst if not provided. Useful when the query port differs from the port players connect to.
-n --name	A display name to show for the server instead of the name it reports.
--list-query-types	Lists every supported query type and exits.

Store Settings

Command	Description
-S --save	When set, adds or saves the server or setting to the store. This persists the server or setting for future sessions.
-D --delete	When set, deletes the server or setting from the store so it will no longer be monitored after the program exits.

When deleting a server, only the destination address and port are required.

Overrides

You can specify overrides for a server when adding it to the store. These overrides will be saved and used whenever the server is monitored in the future.

Command	Description	Default
-t --timeout	The query timeout in milliseconds. This is the amount of time the program will wait for a response from the server before considering it Offline.	2000
-c --query-interval	How often the server is queried, in milliseconds.	1000
--latency-type	How latency is measured: self-info, self-users, self-vars (reuses the timing of the regular query), query-info, query-users, query-vars (sends an extra query) or icmp.	self-info
--latency-interval	How often latency is measured, in milliseconds.	Query interval

Monitor Settings

You can change how the program monitors servers with the following commands.

Command	Description
--query-monitor -M	When set, will only monitor this specific query from the server. The values for this are info, users, and vars. If this option is not set, the program will monitor all queries.
-m --monitor-only	When set, will only monitor the server query specified above.
-I --isolate	When set, will only monitor the server specified through the command line.
