GS - Player Controller
An open source 3D first person player controller for Godot that supports bunny hopping, air strafing, and more!
Everything that drives a player: a shared base, a first-person movement model built for prediction and reconciliation, and a third-person model with a camera rig.
addons/dot_player_controller/
core/, nodes/ intent, look, the abstract base, the switch
fp/ first-person movement (formerly dot-fps-controller; class names unchanged)
tp/ third-person movement and camera rig
You can delete fp/ or tp/ if you only need one. A vehicle, ladder or spectator camera can be written as another controller.
Install
- Copy
addons/dot_player_controller/,addons/dot_player/andaddons/dot_core/into your project. - Enable all three in Project > Project Settings > Plugins.
addons/dot_net/ is optional and only used by DotFpsNetSync.
Needs Godot 4.7 or newer.
The shared base
Intent. DotPlayerIntent says "forward, holding jump, looking here". It is not key presses and not movement, so a sampler, a replay or a server can all produce it.
var intent := DotPlayerIntent.make(Vector2(0, 1), DotPlayerIntent.Btn.JUMP, tick)
intent.view_yaw = look.yaw
controller.simulate(intent, delta)
diff_from(previous_buttons) fills in pressed and released. The look delta is not sent over the network; the client sends where it looks and the server clamps it.
Look. DotPlayerLook handles mouse look: pitch clamps, yaw wraps, sensitivity scales the delta.
look.apply(mouse_delta)
camera.basis = look.basis()
body.basis = look.body_basis()
velocity = look.move_direction(intent.move) * speed
Switch. DotPlayerControllerSwitch makes exactly one controller active and hands over position, velocity, yaw and pitch, not controller state.
DotPlayer
DotPlayerControllerSwitch default_controller = &"fp"
DotFpsController controller_id = &"fp"
DotTpsController controller_id = &"tp"
set_input_enabled(false) freezes every controller but still ticks with an empty intent, so a frozen player keeps falling.
First-person movement
The simulation is a pure function of (state, command, delta, world), so a client can predict and a server can correct without disagreeing. examples/movement_selftest.tscn replays 400 commands from a snapshot and checks the same end state; examples/surf_selftest.tscn tests ramps. It does its own collide-and-slide, because bunny-hopping and surfing depend on the exact sliding.
| Class | Purpose |
|---|---|
DotFpsCommand |
One tick of player intent, packed to 49 bits. |
DotFpsState |
Everything carried between ticks. |
DotFpsTunables |
Every movement number, layered: defaults, JSON, DOT_FPS_* environment, --fps-* command line. Also jump_reach(rise), jump_airtime(rise), climb_limit() for level designers. |
DotFpsMotor |
The deterministic simulation. |
DotFpsBody |
Collision queries: DotFpsPhysicsBody for real geometry, DotFpsFlatBody for tests. |
DotFpsController |
The node. Drives the motor, writes to the scene, resizes the collider. |
DotFpsView |
Camera, pitch, crouch height, speed FOV. Cosmetic, runs per frame. |
DotFpsViewMotion |
Landing dip, strafe and slide roll, wall-run lean as plain numbers, for games with their own camera. |
DotFpsSampler |
Keyboard, mouse and gamepad to commands. |
DotFpsTouchSampler |
Touch to commands. |
DotFpsNetSync |
What to replicate and how, without importing dot-net. |
DotFpsSurface |
Ground behaviour such as ice, mud or a conveyor. |
DotFpsModifier |
A temporary change such as a speed pad, slow field, stun or launcher. |
DotFpsMoveMode |
A movement mode your game adds, such as a ladder, water or grapple. |
Movement features
The defaults are a classic competitive-shooter profile (see docs/motor.md); DotFpsTunables.with_profile("legacy") gives the older set. Features marked "off" are enabled with tunables.
| Feature | Notes |
|---|---|
| Air-strafing and bunny-hopping | Air acceleration is capped by max_air_wish_speed; set it to 0 to disable. |
| Surfing | Steep slopes slide the player. |
| Stair stepping | Up to step_height. |
| Crouching | Resizes the collider and refuses to stand under a low ceiling. |
| Coyote time, jump buffering | Set to 0 to turn off. |
| Ground snapping | Walking down slopes and stairs stays grounded. |
| Sliding (off) | Crouch at a run; slide_duration, slide_boost and a cooldown are tunables. |
| Launch ability (off) | launch_button throws the player up and optionally forward, on a cooldown. |
| Wall running, wall jumping, wall slide (off) | Each is a separate tunable. |
Extending it
- Surfaces: set
dot_fps_surface = "ice"on a collider (or put it in asurface_icegroup) and give the controller aDotFpsSurfaceSet. - Modifiers:
DotFpsModifierscales speed, acceleration, gravity, friction and jumping, denies movement, or applies an impulse. - Admin abilities:
admin_abilities = trueregisters noclip, freeze, and speed and gravity steps that the owning client predicts. - Movement modes: subclass
DotFpsMoveMode. - Sampling: use a sampler, or build a
DotFpsCommandyourself for a bot or demo.
These are part of the simulation, so they replicate and survive replays. See docs/extending.md.
Networking
The controller does not import dot-net. Wiring it up takes about 30 lines; see docs/networking.md. Compare DotFpsTunables.fingerprint() between client and server, because a config mismatch looks like packet loss.
Third-person movement
An orbit rig on a spring arm with a swappable shoulder offset, camera-relative movement, turn-to-face, strafe-lock, coyote time and a jump buffer. DotTpsMotor.step relies on move_and_slide for collisions, so it is repeatable on one machine but not bit-exact against a server. For that, drive the first-person motor and use tp/ only for the camera.
Writing a controller
class MyController extends DotPlayerController:
func _apply_intent(intent: DotPlayerIntent, delta: float) -> void: ...
func _read_transform() -> Transform3D: ...
func _write_transform(to: Transform3D) -> void: ...
func _read_velocity() -> Vector3: ...
func _write_velocity(v: Vector3) -> void: ...
The defaults read and write a CharacterBody3D or CharacterBody2D, so simple controllers can skip four of them. See examples/controller_selftest.gd. All docs: docs/README.md.
Credits
| What | Author / source | License |
|---|---|---|
| Original first-person controller this one started from | BleyChimera | Code basis, now under the repo MIT licence |
| Maintainer | Christian Deacon | MIT |
| Prototype textures | Kenney | CC0 |
Status and licence
Part of the Gamespice platform: a family of Godot addons. Written with Claude Code and maintained by gamemann. Every addon has headless tests, but little of this has been played by real users yet, so expect rough edges and please open an issue when you hit one.
MIT licence, see LICENSE. The only closed part of the Gamespice platform is the web back end; you can use your own instead of Gamespice's.
